RZS
Rhovanion (BB-1915)
Back to
Zealandia Ships
List
During the worldwide Dreadnought race that lead up to World War One, the
Zealandian Navy was under pressure to follow the Royal Navy lead in going from
12" to 13.5" then 15" guns. The Zealandian Navy had actually circumvented this
by going to the 14" gun early. First in twins then in triples to be fitted to
the Rhovanion class. The one thing the Zealandians did follow was the Queen
Elizabeth's increase in speed from the fleet 21 knots to 25 knots for the new
ships. Like most Zealandian capital ships only two were authorised to be built.
There were plenty of other innovations that were placed aboard the Rhovanion
class. The raised 14" mount forward kept it dry when compared to the 'A'
mountings on a lot of the bow heavy Royal Navy battleships. The raised foredeck
allowed for the placement of four 6" casemate guns that could fire full forward
over the bow. These guns however, were only useable in good sea conditions.
Taking it green over the bow washed out the casemates and made conditions very
wet. They had been placed there to stop destroyers attacking from the bow, but
this advent was not carried on to any other Commonwealth Navy.
The Zealandian Navy liked the ships, and kept them virtually continually in
service from when they were commissioned for service in 1915 right through to
1935 when they were taken in hand for a Life Extension Rebuilding.
| Displacement |
30,000 tons standard, 34,500 tons full load |
| Length |
647 ft |
| Breadth |
100 ft |
| Draught |
29 ft |
| Machinery |
4 shaft, steam turbines, 85,000shp |
| Speed |
25 knots |
| Range |
8000 miles at 14 knots |
| Armour |
13" side, 2" deck, 12"/8"/5.5" turrets |
| Armament |
9 x 14" (3x3)
16 x 6" (16x1)
10 x 4" (6x1)
4 x 2pd (4x1) |
| Aircraft |
nil |
| Torpedoes |
2 x 18" (2x1 submerged) |
| Complement |
1490 (1540 as Flagship) |
| Notes |
RZS Rhovanion (03/1915)
RZS Lothlorien (05/1915) |
The rebuilding of the Rhovanion class was quite comprehensive with new bridge
superstructures, funnel, aircraft handling arrangements, new 4.5" heavy AA guns,
2pd AA guns, new propulsion systems, deck armour, and most of all, up to date
fire control systems. The main battery gunnery controller was fitted with
Zealandias first Radar gunnery assistance set. While this was not much better
than the mark one eyeball it gave a good indication of what was to come,
especially at night.
New Drawing to make the new rebuilt model look a little less bulky and topheavy.
Removed the forward 6",I can't see them being retained.
| Displacement |
31,400 tons standard, 37,500 tons full load |
| Length |
647 ft |
| Breadth |
100 ft, 108 ft over bulges |
| Draught |
29 ft |
| Machinery |
4 shaft, steam turbines, 100,000shp |
| Speed |
25 knots |
| Range |
9000 miles at 14 knots |
| Armour |
13" side, 5.5" deck, 12"/8"/5.5" turrets |
| Armament |
9 x 14" (3x3)
20 x 4.5" (10x2)
48 x 2pd (6x8)
4 x 20mm (4x1) |
| Aircraft |
3 |
| Torpedoes |
nil |
| Complement |
1550 (1610 as Flagship) |
Twin 4.5" as fitted to the Rhovanion class rebuilt battleships.
