Heraklion Class Heavy cruiser.
Return to Tyrrhenian Navy page:
The Heraklion was laid down in late 1939 in answer to the big German, British,
American, French, Italian, Russian, cruisers being built at the end of the
1930's as those countries explored the upper limits of the heavy cruiser and
into the American designation 'Large' cruiser (CB). Everybody was doing it.
However Tyrrhenia surrendered in 1943 with the Heraklion at about 70% complete. 1945 and
the Tyrrhenian Admiralty reviews what is left to them after the victorious
Allies have been through and grabbed all the best ships and discarded most of
the rest. The Heraklion, while an older design, has already had a lot of
investment in it and it would serve the Tyrrhenian Fleet for 30-40 years if
completed. The original design was reviewed and Tyrrhenia went cap in hand to
the US and asked if they could purchase modern tertiary armaments, fire control and Radar to
complete the ship. The US agreed and packed up and sent the systems.
The new parts from America arrived during 1946 and were incorporated into the
new design. Air defence was now one of the major roles of the Heraklion with the
automatic 3" and 5"/38cal guns playing the leading roles aboard ship.
The new 10"/45 calibre guns were an upgraded, upsized version of the 9.2" that
were still in service aboard the Syracuse class cruisers. It fired a 580 pound
shell, 30,000 yards and was a very good, accurate gun. Only once did the
Heraklion get to fire its guns in anger. 1975 and the Heraklion shelled Lebanese
dissidents as it covered the withdrawal of non-Lebanese citizens out of the
civil war zone.
Displacement | 16,250 tons standard, 21,000 tons full load | |
Length | 668 ft | |
Breadth | 77 ft | |
Draught | 23 ft | |
Machinery | 4 shaft Parsons turbines, 120,000shp | |
Speed | 32 knots | |
Range | 8000 miles at 15 knots | |
Armour | 6in belt, 4in decks, 8"/5"/3" turrets | |
Armament | As Designed 1940 8 x 10" (4x2) 12 x 3.9" (6x2) 12 x 40mm (6x2) 16 x 20mm (8x2) |
As Completed 1948 8 x 10" (4x2) 16 x 5" AA (8x2) 10 x 3" (5x2) 4 x 40mm (2x2) |
Aircraft | 2 | 0 |
Complement | 785 | 780 |
Notes | TNS Heraklion |
Automatic 3" replaced almost all of the 40mm due to the greater knockdown power
of the 3".
