CNS Capitan Prat (LBC-1937)
Back to Chilean Navy page
This ship replaced the 4 old armoured/protected cruisers that had been
the mainstay of the Chilean Navy till the advent of the Royal Navy reparation
deal. Because Chile was outside the various Treaties then in force, the Chileans
could choose what sort of armament they wanted their new cruiser to carry. The
Chileans had had the foresight to buy the twin 10" from the Swiftsure class.
Described by Janes Fighting Ships as a light Battlecruiser, the ship was a
design by Lillicrap (the cruiser King) while he was chief designer for the Royal
Navy.
Being clear of treaties these ships were able to be bigger and were able to have thicker armour for both side and deck armour. Some thought
to had been made to dispense with the aircraft handling facilities and use the
space to improve the AA armament. However it was felt as no South American
country had much of an air force that having scouting facilities, by having their
own aircraft aboard, would be an asset.
Displacement | 22,750 tons std, 26,850 tons full load |
Length | 666 ft |
Breadth | 82 ft |
Draught | 26 ft |
Machinery | 4shaft steam turbines, 120,000shp |
Speed | 32 knots |
Range | 6500 miles at 15 knots |
Armour | 8" side, 4" deck, 8" turrets |
Armament | 8 x 10" (4x2) 12 x 4" (6x2) 24 x 2pd (1x8, 4x4) 16 x 0.5" mg (4x4) |
Aircraft | 3 |
Torpedoes | 6 x 21" (2x3) |
Complement | 810 |
Notes | Capitan Prat (06/1937) |
Old drawing of the Capitan Prat. Good idea but wrong result.
